PT3000 Series Configurable Phase 1 - 20kVA
Santak PT-3000 Series adalah UPS online generasi baru yang efisien dan serbaguna. Tersedia dalam kapasitas 1 hingga 20kVA, seri ini menawarkan performa tinggi, desain ringkas, dan fleksibilitas input/output (termasuk konfigurasi 1:1 / 1:3 / 3:1 / 3:3 untuk 20kVA). Cocok untuk rumah, kantor, server, workstation, sistem kontrol industri, dan perangkat penting lainnya. Didukung fitur manajemen pintar, efisiensi tinggi hingga 96%, dan desain tahan lingkungan.
Kapasitas
Cocok untuk:
- Server & NAS
- Retail, POS, & ATM
- Perangkat Kontrol Industri & Otomasi
- Ruang Data & Infrastruktur IT Skala Kecil-Menengah
- Fasilitas Medis & Lab
Beli di:
Output Power Factor 1
Efisiensi hingga 96% (Online) / 98% (ECO)
Rackmount 3U, kedalaman <600 mm
Konfigurasi input/output fleksibel (1:1, 3:1, dll.)
Programmable Output Socket
Intelligent Battery Management
Kompatibel VMware & Hyper-V
Perlindungan penuh terhadap pelepasan daya berlebih, pengisian daya berlebih, dan beban berlebih
| Model | PT1K-i | PT1KS-i | PT2K-i | PT2KS-i | PT3K-i | PT3KS-i | PT 6K | PT 6KS | PT 10K | PT10KS | PT 10KS31 | PT15KS | PT20KS | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Output | Power rating | 1kVA/1kW | 2kVA/2kW | 3kVA/3kW | 6kVA | 6kVA | 10kVA | 10kVA | 10kVA | 15kVA | 20kVA | |||
| Power factor (PF) | 1 | |||||||||||||
| Output voltage | 220V default (200/208/220/230/240 VAC optinal) | 220V/230V/240V | ||||||||||||
| Output voltage regulation | ± 1 % | Single phase 220V/230V/240V | Single phase 220V/230V/240V, Three phase 380V/400V/415V | |||||||||||
| Output frequency | 50Hz/60Hz | (50/60±0.1) Hz | ||||||||||||
| Output wiring | Single phase with ground | Single phase 3 wire (L,N,G) | Single phase 3 wire (L,N,G) / Three phase 5 wire (L1/L2/L3/N/G) | |||||||||||
| THDV | <1% | |||||||||||||
| Crest factor | 3:1 | ≥3 | ||||||||||||
| Efficiency @ Online mode | 95% | up to 96% | ||||||||||||
| Efficiency @ ECO mode | up to 96% | up to 97% | up to 97% | 98% | up to 98% | up to 99% | ||||||||
| Overload | 125%, 10mins | |||||||||||||
| Input | Input voltage range | 110~300VAC (<160VAC need derating) | 100VAC-275VAC | Single phase 110VAC~275VAC Three phase 191VAC~476VAC | Single phase 100VAC~300VAC Three phase 173VAC~520VAC |
|||||||||
| Input wiring | Single phase with ground | Single phase 3 wire (L,N,G) / Three phase 5 wire (L1/L2/L3/N/G) | ||||||||||||
| Input frequency range | 45 Hz – 55 Hz (50Hz) / 54 Hz – 66 Hz (60Hz) | 40~70Hz | ||||||||||||
| Power factor (PF) | ≥ 0.99 | |||||||||||||
| THDi | <5% | <3% | ||||||||||||
| Battery | Battery voltage | 36VDC | 72VDC | 72VDC | 192VDC default (192V~240V adjustable) | 192VDC (192V~240V adjustable) | ± 192VDC (±192V to ±240V adjustable) | |||||||
| Internal battery (Ah*Qty) | 7Ah*3 | 无 | 7Ah*6 | 无 | 9Ah*6 | 无 | ||||||||
| Charge current | 1.5A | 4A default (2/6/8A optional) | 1.5A | 4A default (2/6/8A optional) | 1.5A | 4A default (2/6/8A optional) | 1.4A default ( 0-4A adjustable) | 4A default ( 2-12A adjustable) | 2A default ( 0-4A adjustable) | 4A default ( 2-12A adjustable) | 4A default, 0-12A adjustable | 2A default, 0-13A adjustable | ||
| Charge temperature compensation | Yes | |||||||||||||
| EBM model | PTB9032-i | PTB9062-i | PTB7161 | PTB9161 | PTB9161 | PTB9321 | ||||||||
| EBM battery (Ah*Qty) | 9Ah*6 | 9Ah*12 | 7Ah*16 | 9Ah*16 | 9Ah*16 | 9Ah*32 | ||||||||
| Input & output connection | Inlet | IEC C14 | IEC C20 | |||||||||||
| Output socket | Main output: 4*IEC C13 Programmable output: 4*IEC C13 | Main output: 1*IEC C19 + 4*IEC C13 Programmable output: 4*IEC C13 | ||||||||||||
| Communication & interface | Interface | LCD | Touch LCD, auto rotate according to install direction | |||||||||||
| Communication | USB / RS232 / EPO / Slot card / Dry contact | |||||||||||||
| Physical parameters | Installation type | Rack/tower | ||||||||||||
| UPS W*D*H (rack type) | 438*445*85.5 mm (2U) | 438*600*85.5 mm (2U) | 438*86.3*573 | 438*86.3*573 | 438*86.3*573 | 438*86.3*573 | 438*573*86.3mm | 438*589*129mm | ||||||
| UPS net weight | 14.3 kg | 8.0 kg | 23.3 kg | 10.6 kg | 26.2 kg | 11.0 kg | 14kg | 14.4kg | 15.9kg | 16.3kg | 16.2kg | 23.7kg | ||
| EBM W*D*H (rack type) | 438*445*85.5 mm (2U) | 438*600*85.5 mm (2U) | 438*594*130mm | 438*594*130mm | 438*559*129mm *2 | |||||||||
| EBM net weight | 22.6kg | 39.9kg | 43.2kg | 50kg | 50kg | 51.8kg *2 | ||||||||
| Environment | Temperature | 0 ºC ~ 50 ºC (>40 ºC derating) | ||||||||||||
| Humidity | 0 ~ 95% | |||||||||||||
| Altitude | 0~3000m (>1000m derating) | |||||||||||||
| Protection Class | IP20 | |||||||||||||
| Standard | IEC 62040 | |||||||||||||
